Bright Speed 16 Slice

The BrightSpeed 16 Slice CT Scanner delivers high-quality images with its 16-slice capability, allowing for detailed visualization of anatomical structures.

Description

The BrightSpeed 16 Slice CT Scan Machine is a high-performance imaging system designed to provide exceptional diagnostic capabilities with 16 slices per rotation. This system is ideal for a wide range of clinical applications including cardiac, neuro, thoracic, and abdominal imaging. It offers a blend of advanced technology, user-friendly operation, and efficient performance, making it a reliable and versatile tool for healthcare providers.

Featured Service

The 16-slice configuration allows for faster scanning times, which reduces patient time in the scanner and increases throughput. This efficiency is crucial in busy clinical environments, ensuring quick and accurate diagnostics.

X-ray Tube Voltage: 80-140 kVp (adjustable)
X-ray Tube Current: 10-500 mA (adjustable)
Gantry Aperture: Approximately 70 cm
Maximum Scan FOV (Field of View): Typically 50 cm
Table Load Capacity: 200-225 kg
Scan Time per Rotation: 0.4-0.6 seconds
Slice Thickness: 0.625-5 mm (variable)
Spatial Resolution: High resolution with matrix size options, e.g., 512x512

Reconstruction Speed: Typically 20-25 images per second
Power Supply: 220-240V, 50/60Hz
Power Consumption: Approximately 20-30 kW
Operating Temperature Range: 18-24°C
Operating Humidity Range: 30-75% non-condensing
Dimensions: Approximately 150 cm (W) x 180 cm (H) x 140 cm (D)
Weight: Approximately 1200-1600 kg
Certifications: CE, FDA (if applicable)
